1. Features:
• Magnetic Latching Energy-Saving Design: The core relay unit is a magnetic latching type, requiring only a pulse drive to switch and lock the state. The module's overall static power consumption is extremely low, reducing system heat generation and energy consumption.
• Standardized Rail Mounting: Uses standard DIN rail mounting, with a modular structure design that supports flexible combination and expansion. Installation, maintenance, and system expansion are simple and quick.
• High-Density High-Load Integration: Integrates up to 16 relay channels in a compact module space, with each channel supporting up to 10A-16A load switching capacity, resulting in high power density and space utilization.
2. Key Characteristics:
• Flexible Channel Configuration: Provides various channel specifications, including single-channel, 4-channel, 8-channel, and 16-channel options, to meet the needs of different control point scales.
• Integrated Interface Design: Equipped with unified power input terminals, standardized control signal interfaces (such as high-level/low-level active, common anode/common cathode selectable), and clear load output terminals for standardized wiring.
• Status Indication and Protection: Each channel is equipped with independent contact status mechanical indicators or LED indicators. The module often integrates circuits for power reverse connection protection, overcurrent protection, and surge absorption.
• Industrial-Grade Reliability: Designed to meet industrial environment requirements, with good electrical isolation, vibration resistance, and electromagnetic interference resistance.
3. Main Applications:
• Energy-Saving Industrial Control Cabinets: Used in control cabinets for the main circuits of multiple motors, valves, and lighting, significantly reducing heat generation and energy consumption during long-term operation of the control cabinet.
• Smart Meters and Energy Management Boxes: Integrated into centralized meter boxes and photovoltaic combiner boxes to achieve remote on/off control of multiple users, relying on magnetic latching characteristics for maintenance-free operation. • Security and Fire Emergency Systems: Used for critical circuits such as emergency lighting control and fire pump control, ensuring that relay states do not reset unexpectedly in the event of a sudden power outage.
• Automated Production Line Power Management: Provides grouped and centralized power management for multiple workstations or equipment on the production line, enabling energy-saving scheduling and safety isolation.
Single, 4 groups, 8 groups, 16 groups,
